LiFeP04 RatPack

R19,999.00

The Summit LiFeP04 RatPack is a versatile, portable, solar-ready power system. Whether you need a power backup solution at home or access to power in remote locations, the RatPack is the solution. It combines a smart pure sine wave inverter with a powerful Lithium-ion battery to give you a complete mobile power system that can work on or off the grid. The RatPack can be charged via the grid, your car, or one of our portable solar panels. It features a variety of outputs to ensure you have access to power, no matter what you need.

Its compact, easy-to-carry design enables you to take this power system wherever you go — home, office, and outdoors — offering you one solution for all your needs.

KEY FEATURES

1 000W Pure Sine Wave AC Inverter
120Ah (1 500Wh) Capacity Lithium Battery
25A DC Charger (Solar Panel Ready)
12V DC Outputs: Hella, USB and Anderson
220V AC Outputs: 3 Prong and 2 Prong plugs

Available on backorder

Description

A VERSATILE, PORTABLE, SOLAR-READY POWER SYSTEM

The Summit LiFeP04 RatPack is a versatile, portable, solar-ready power system. Whether you need a power backup solution at home or access to power in remote locations, the RatPack is the solution. It combines a smart pure sine wave inverter with a powerful Lithium-ion battery to give you a complete mobile power system that can work on or off the grid. The RatPack can be charged via the grid, your car, or one of our portable solar panels. It features a variety of outputs to ensure you have access to power, no matter what you need.

Its compact, easy-to-carry design enables you to take this power system wherever you go — home, office, and outdoors — offering you one solution for all your needs.

KEY FEATURES

1KW INVERTER

The RatPack is fitted with a 1000W Pure Sine Wave AC inverter.

120AH LITHIUM BATTERY

The RatPack features a 120Ah (1500Wh) LiFeP04 lithium battery.

220V AC OUTPUTS

The RatPack features 2 x 2-prong and 1 x 3-prong 220V outputs.

12V DC OUTPUTS

The RatPack features USB, USB-C, Hella, and Anderson 12V DC outputs.

PORTABLE

You can use the RatPack wherever you go and whenever you need it.

SOLAR-READY

The RatPack is fitted with a 25A DC charger and is solar panel compatible.

TECHNICAL DETAILS

INPUTS
AC INPUT
  • AC input range: 185V-AC – 265V-AC
  • Frequency: 50Hz ± 10Hz
SOLAR INPUT
  • Voltage range: 15V – 50V (VOC 50V max)
  • Power: 375W
ALTERNATOR INPUT
  • Voltage range: 12V – 16V
  • Charge turn ON: 13,2V ± 0,1V
  • Charge turn OFF: 12,8V ± 0,1V
IGNITION INPUT
  • Charge turn ON: 12,0V ± 0,1V
  • Charge turn OFF: 11,0V ± 0,1V
OUTPUTS (12V – DC)
  • Total output current: 50A
  • Brad Harrison socket: 50A
  • Hella socket (x1): 10A
  • Cigarette lighter socket: 10A
  • Dual USB socket: QC3
CHARGING
AC CHARGER
  • Charge voltage: 14,4V ± 0,1V
  • Max charge current: 15,0A ± 1,0A
MPPT SOLAR CHARGER
  • Charge voltage: 14,4V ± 0,1V
  • Max charge current: 25,0A ± 1,0A
DC-DC CHARGER (FROM VEHICLE)
  • Charge voltage: 14,4V ± 0,1V
  • Max charge current: 25,0A ± 1,0A
INVERTER
  • Output voltage: 220V-AC ± 10V-AC
  • Frequency: 50Hz ± 5Hz
  • Type: Pure Sine Wave
  • Peak power: 2 000W
  • Continuous power: 1 000W
BATTERY
  • Type: Lithium-ion (LiFeP04)
  • Capacity: 120Ah
  • Usable capacity: 100A
  • BMS current overload: 60A
  • BMS cut out (low): 11,0V
  • BMS cut out (high): 14,6V
AUX INPUT/OUTPUT
  • Max current: 50A
DIMENSIONS
  • Width: 215 mm
  • Length: 430 mm
  • Height: 290 mm
  • Weight: 20 kg

Additional information

Weight 20 kg
Dimensions 43 × 21.5 × 29 mm
